GAS TURBINE GENERATOR SET

VPS4

VPS series generator sets are designed for reliable power generation in a variety of Industrial and Oil & Gas applications. Proven modular design simplifies and reduces on site installation time and construction costs.

< BACK TO OIL & GAS
< BACK TO INDUSTRIAL POWER GENERATION
VPS4 Image

RELIABLE PROVEN POWER

ISO CERTIFICATION 9001:2019

Our management system has been certified by SGS

PRODUCT BROCHURE

VPS Series gas turbine generator sets for power generation, combined heat & power or offshore power applications

SPECIFICATIONS

VPS3VPS4
Power3,036 kw3,493 kw
Heat Rate12,715 btu/kwh
13,415 kj/kwh
11,979 btu/kwh
12,639 kj/kwh
Thermal Efficiency26.9 %28.5 %
Exhaust Temperature1,092 F
589 C
1,075 F
579 C
Exhaust Flow28.2 lbs/s
12.8 kg/s
30.3 lbs/s
14.2 kg/s
Weight64,000 lbs
29,030 kgs
68,000 lbs
30,844 kgs
Length25.30 ft
7.72 m
25.30 ft
7.72 m
Height20.00 ft
6.10 m
20.00 ft
6.10 m
Width8.60 ft
2.64 m
8.60 ft
2.64 m

APPLICATIONS

  • Simple Cycle Power Generation
  • Combined Heat & Power
  • Distributed Energy



  • Peaking
  • Emergency or Standby Power
  • Offshore Power

BENEFITS

  • High reliability and availability from proven robust aero-derivative design gas turbine
  • Low maintenance costs, 60,000 hrs between major overhauls
  • Utilizes clean and economical natural gas, including treated wellhead gas
  • Low emissions, easy to permit
  • High part load efficiency from twin shaft design
  • High quality exhaust heat stream can be used in other processes
